CyBio SELMA Series Your Personal Assistant - Inspiring Technology Making Pipetting so Much Easier
- Intuitive operation without the need for programming
- Compact design which fits on any lab bench as well as into most of the laminar flow hoods
- Comfortable and error free transfer of 96 or 384 samples in a single step
CyBio SELMA is a smart and compact benchtop solution which supports you in any situation and makes your laborious pipetting tasks so much easier. It offers more comfort, higher performance and more flexibility. Thus you will be faster, more efficient, and more competetive.
Your Personal Pipetting Assistant
Precise and semi-automatic pipettor with 96 or 384 pipetting channels for easy and fast filling of 96- and 384-well microplates without the use of a computer. Applications like replication and reformatting, medium exchange as well as serial dilution can be executed reproducible and convenient.
- Fast and precise processing of 96- and 384-well microplates without the need for programming
- Simple and intuitive operation via user guided methods
- Easy and fast tip changing with ready to use CyBio TipTrays
- Error-free and reproducible results due to 96 or 384 parallel pistons and proven tip sealing principle
- Memory function and automatic use of pipetting heights and liquid handling parameters
- Applications like the replication or the reformating of whole microplates can be executed in seconds
- Save your valuable lab space
- Simplify your pipetting tasks
- Comfortable and Precise in every detail
Brochures
| Title | Language | Info |
|---|---|---|
| Brochure-Liquid-Handling-PlatformAutomation Solutions | en | PDF, 799 KB |
| Brochure CyBio SELMA (EN) | en | PDF, 504 KB |
| Brochure LabAutomation Product Overview (EN) | en | PDF, 537 KB |
| Brochure LabAutomation Product Overview (EN) | en | PDF, 537 KB |
| Brochure Product Guide Life Science (EN) | en | PDF, 2 MB |
| Overview Pipetting Tips for Liquid Handling Instruments (EN) | en | PDF, 2 MB |
CyBio SELMA - Experience More Comfort, Flexibility And Precision While Discovering the Easyness of Automated Pipetting
CyBio SELMA is a semi-automatic pipettor with minimal required space. Optimized for a fast and precise processing of 96- and 384-well microplates without the need for programming. This allows an easy and reproducible transfer of 96 or 384 samples in only one pipetting step. All movements and processes that are crucial for high precision and reproducibility are performed by reliable drives. CyBio SELMA is extremely easy to operate without the need for a separate computer control system. Pipetting, dispensing, mixing and further pipetting modes are directly selectable and the intuitive user guidance via touch screen allows for the easy creation of an liquid handling workflow.
- Compact footprint and fits on any lab bench as well as into most laminar flow hoods
- Easy and intuitive operation via touch screen, user guided and comfortable saving of methods without programming
- Automatic tip tightening function reduce time. Pre-loaded tip magazines ensure immediate use. Tips are changed within seconds
- No more strenuous and monotonous pipetting by hand, no more empty or inaccurate filling of wells and no more repetition of tests because of pipetting inaccuracies – CyBio SELMA enables a safe and error free transfer of 96 or 384 samples in a single step.
Products
CyBio SELMA 96/250 µL
Semi-automated pipetting station, instrument system stand alone, including a 96 channel pipetting head from 5 till 250 µl and 2 working positions for 96 well plates
Order number: OL7001-26-213
CyBio SELMA 384/25 µL
Semi-automated pipetting station, instrument system stand alone, including a 384 channel pipetting head from 0.5 till 25 µl and 2 working positions for 384 well plates
Order number: OL7001-26-216
CyBio SELMA 384/60 µL
Semi-automated pipetting station, instrument system stand alone, including a 384 channel pipetting head from 1 till 60 µl and 2 working positions for 384 well plates
Order number: OL7001-26-217
CyBio SELMA 96/1000 µL
Semi-automated pipetting station, instrument system stand alone, including a 96 channel pipetting head from 10 till 1000 µl and 2 working positions for 96 well plates
Order number: OL7001-26-214
CyBio SELMA 96/25 µL
Semi-automated pipetting station, instrument system stand alone, including a 96 channel pipetting head from 0.5 till 25 µl and 2 working positions for 96 well plates
Order number: OL7001-26-211
CyBio SELMA 96/60 µL
Semi-automated pipetting station, instrument system stand alone, including a 96 channel pipetting head from 1 till 60 µl and 2 working positions for 96 well plates
Order number: OL7001-26-212
Technical Data
Plate Formats | Interchangeable Heads | Single Channel Pipetting | Deck Positions | Tube Formats | Parallel Pipetting | Column Pipetting | Row Pipetting | Pipetting Channels | Volume Range | Pipetting Tips | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| CyBio SELMA 96/250 µL | ANSI/SLAS format, MTP and DWP | No | No | 2 | No | Yes | Yes | No | 96 | 5-250 µL | Disposables |
| CyBio SELMA 384/25 µL | ANSI/SLAS format, MTP and DWP | No | No | 2 | No | Yes | Yes | No | 384 | 0.5-25 µL | Disposables |
| CyBio SELMA 384/60 µL | ANSI/SLAS format, MTP and DWP | No | No | 2 | No | Yes | Yes | No | 384 | 1-60 µL | Disposables |
| CyBio SELMA 96/1000 µL | ANSI/SLAS format, MTP and DWP | No | No | 2 | No | Yes | Yes | No | 96 | 10-1000 µL | Disposables |
| CyBio SELMA 96/25 µL | ANSI/SLAS format, MTP and DWP | No | No | 2 | No | Yes | Yes | No | 96 | 0.5-25 µL | Disposables |
| CyBio SELMA 96/60 µL | ANSI/SLAS format, MTP and DWP | No | No | 2 | No | Yes | Yes | No | 96 | 1 - 60 µL | Disposables |
Order Information
Order number | Description |
|---|---|
| OL7001-26-213 | CyBio SELMA 96/250 µl, stand alone, semi-automated pipetting station |
| OL7001-26-216 | CyBio SELMA 384/25 µL, stand-alone, semi-automated pipetting station |
| OL7001-26-217 | CyBio SELMA 384/60 µL, stand -alone, semi-automated pipetting station |
| OL7001-26-214 | CyBio SELMA 96/1000 µL, stand -alone, semi-automated pipetting station |
| OL7001-26-211 | CyBio SELMA 96/25 µL, stand-alone, semi-automated pipetting station |
| OL7001-26-212 | CyBio SELMA 96/60 µL, stand-alone, semi-automated pipetting station |
Accessories
8-Channel Magazine 1000 µL
Order number: OL5022-25-115
8-Channel Magazine 25 µl/60 µL
Order number: OL7001-25-940
16-Channel Magazine 25 µL/60 µL
Order number: OL7001-25-955
8-Channel Magazine 250 µL DW
Order number: OL7001-25-900
Tip Magazine 96/1000 µL
Order number: OL5022-25-112
CyBio SELMA Protective Cover
Order number: OL7001-25-950
Microplate Adapter 384
Order number: OL7001-24-976
Side Touch Adapter
Order number: OL7001-25-927
Special table CyBio SELMA
Order number: OL7001-24-960
Tip magazine 384/25 µL
Order number: OL3191-116-25
Tip magazine 384/60 µL
Order number: OL3384-25-617
Tip magazine 96 Zip Tip
Order number: OL3396-237-25
Tip magazine 96/25 µL
Order number: OL3397-25-354
Tip magazine 96/250 µL
Order number: OL3391-112-25
Tip magazine 96/60 µL
Order number: OL3384-25-717
Tip Transfer Tool 96/250 - 1000 µL
Order number: OL3396-25-354
Tip transfer tool 384/10 µL - 25 µL
Order number: OL3191-350-25
Tip transfer tool 96 Zip Tip
Order number: OL3396-350-25
Tip transfer tool 96/25 µL-60 µL
Order number: OL3397-25-350
UV Display Protection CyBio SELMA
Order number: OL7001-10-530
Consumables
| Order number | Name |
|---|---|
| OL3800-25-501-B | CyBio Tips 10 µL; bulk |
| OL3800-25-503-B | CyBio Tips 25 µL; bulk |
| OL3800-25-508-B | CyBio Tips 250 µL DW; bulk |
| OL3800-25-507-B | CyBio Tips 250 µL SW; bul |
| OL3800-25-505-B | CyBio Tips 60 µL; bulk |
| OL3800-25-512-N | CyBio TipTray 384/10 µL |
| OL3800-25-712-P | CyBio TipTray 384/10 µL; PCR-certified, pre-sterilized |
| OL3800-25-915-F | CyBio TipTray 384/18 µL DW; PCR-certified, pre-sterilized, filter |
| OL3800-25-513-N | CyBio TipTray 384/25 µL |
| OL3800-26-513-N | CyBio TipTray 384/25 µL; large pack |
| OL3800-25-713-P | CyBio TipTray 384/25 µL; PCR-certified, pre-sterilized |
| OL3800-25-913-F | CyBio TipTray 384/25 µL; PCR-certified, pre-sterilized, filter |
| OL3800-25-515-N | CyBio TipTray 384/60 µL |
| OL3800-25-715-P | CyBio TipTray 384/60 µL; PCR-certified, pre-sterilized |
| OL3800-25-532-N | CyBio TipTray 96/10 µL |
| OL3800-25-732-P | CyBio TipTray 96/10 µL; PCR-certified, pre-sterilized |
| OL5022-25-371 | CyBio TipTray 96/1000 µL |
| OL5022-25-374 | CyBio TipTray 96/1000 µL; PCR-certified, pre-sterilized |
| OL5022-25-379 | CyBio TipTray 96/1000 µL; PCR-certified, pre-sterilized, filter |
| OL3800-25-533-N | CyBio TipTray 96/25 µL |
| OL3800-25-733-P | CyBio TipTray 96/25 µL; PCR-certified, pre-sterilized |
| OL3800-25-933-F | CyBio TipTray 96/25 µL; PCR-certified, pre-sterilized, filter |
| OL3800-25-559-N | CyBio TipTray 96/250 µL DW |
| OL3800-26-559-N | CyBio TipTray 96/250 µL DW; large pack |
| OL3800-25-759-P | CyBio TipTray 96/250 µL DW; PCR-certified, pre-sterilized |
| OL3800-25-959-F | CyBio TipTray 96/250 µL DW; PCR-certified, pre-sterilized, filter |
| OL3800-25-557-N | CyBio TipTray 96/250 µL SW |
| OL3800-25-757-P | CyBio TipTray 96/250 µL SW; PCR-certified, pre-sterilized |
| OL3800-25-535-N | CyBio TipTray 96/60 µl |
| OL3800-25-735-P | CyBio TipTray 96/60 µL; PCR-certified, pre-sterilized |
| OL3800-25-935-F | CyBio TipTray 96/60 µL; PCR-certified, pre-sterilized, filter |
Downloads
| Title | Language | Info |
|---|---|---|
| Brochure CyBio SELMA (EN) | English | PDF, 504 KB |
| Brochure LabAutomation Product Overview (EN) | English | PDF, 537 KB |
| Brochure Product Guide Life Science (EN) | English | PDF, 2 MB |
| Brochure-Liquid-Handling-PlatformAutomation Solutions | English | PDF, 799 KB |
| Overview Pipetting Tips for Liquid Handling Instruments (EN) | English | PDF, 2 MB |
