CyBio QuadPrint Series Stack Plates. Print Quad.

Save your valuable lab space – Small footprint despite high capacity microtiter plate storage

Ensure high process stability and efficiency – Precise printing

Operate reliable and reproducible − Harmonic device and software technology

Reach maximum flexibility −Increasing throughput without compromise

Compact, robust, versatile – the CyBio QuadPrint high-throughput label printer makes your labeling processes safe and reliable, with maximum walk-away time.

Compact, high speed and precise label print and apply solution

The novel barcode labeler CyBio QuadPrint sets higher standards in high speed microplate labeling. It features a very small footprint, flexible labeling on all four sides of the microplate as well as an automatic label height adjustment.

  • Direct transfer from stack to label position
  • User friendly software with CyBio PrintStudio (GUI)
  • Based on the new ergonomic stacker system CyBio QuadStack

Download Product Information

Printer and Stacker in One Device

Printer and plate storage form a unique unit that enables fully automated microtiter plate (MTP) loading, labeling and storage on a comparatively small footprint. Thanks to the re-duced required dimensions of the device, the CyBio QuadPrint can be operated on the standard laboratory bench or integrated into automation systems.

The precise labelling of the microtiter plates by the CyBio QuadPrint allows the required process stability in pharmaceutical and life science laboratories, especially in downstream applications. The accurate positioning of a easily readable label ensures the successful reading of the barcode and thus a trouble-free execution of the workflow. Special diligence is required when applying long, thin labels, such as those used for labeling microtiter plates.

Automating the labeling process leads to a prevention of human errors and an increased efficiency in laboratory processes.The reliability of the system is achieved through robust de-vice technology combined with error-tolerant device control. The combination of CyBio Composer with the improved CyBio PrintStudio enables reliable operation of the CyBio QuadPrint. This includes the ergonomic design of label lay-outs as well as the import of label lists and printing of MTP labels. Thanks to a low-maintenance, high-performance label printer and suitable labels, the system easily can with-stand the rough conditions in production environments.

The CyBio QuadPrint has a very high stacker capacity (up to 280 MTPs) and allows the processing of different microplate formats in ANSI SLAS format. The combination of excellent labeling speed, a comprehensive database with predefined microplate parameters and a wide range of label contents (barcode, text, 1D and 2D) makes the CyBio QuadPrint a flexible partner in automated high-throughput labeling.

Products

CyBio QuadPrint HQ-M

Printer and plate storage (standard stacker length 555 mm) form a unique unit that enables fully automated microtiter plate (MTP) loading, labeling and storage on a comparatively small footprint.

Order number: OL5004-26-027

CyBio QuadPrint HQ

Printer that enables microtiter plate (MTP) labeling on a comparatively small footprint for integration in automation environment.

Order number: OL5004-26-025

CyBio QuadPrint HQ-L

Printer and plate storage (extended stacker length 755 mm) form a unique unit that enables fully automated microtiter plate (MTP) loading, labeling and storage on a comparatively small footprint.

Order number: OL5004-26-026

Technical Data

Label Characteristics

Barcode Types

Label Size

System Capacities

Labware Compatibility

Dimension (width x depth x height)

CyBio QuadPrint HQ-M
OL5004-26-027

Resistant to chemcials, wipes/scratch, moisture Code39, Code128, 2of5interleaved, QR Code, Aztec Code, Data Matrix, Maxi Code, PDF-147 66.0 mm x 7.0/5.5 mm up to 280 plates ANSI SLAS format, shallow well, deep well, high base, low profile microplates, tip boxes 932.5 mm x 441.8 mm x 1095.7 mm

CyBio QuadPrint HQ
OL5004-26-025

Resistant to chemcials, wipes/scratch, moisture Code39, Code128, 2of5interleaved, QR Code, Aztec Code, Data Matrix, Maxi Code, PDF-147 66.0 mm x 7.0/5.5 mm no plate storage ANSI SLAS format, shallow well, deep well, high base, low profile microplates, tip boxes 732.5 mm x 424.2 mm x 726 mm

CyBio QuadPrint HQ-L
OL5004-26-026

Resistant to chemcials, wipes/scratch, moisture Code39, Code128, 2of5interleaved, QR Code, Aztec Code, Data Matrix, Maxi Code, PDF-147 66.0 mm x 7.0/5.5 mm up to 280 plates ANSI SLAS format, shallow well, deep well, high base, low profile microplates, tip boxes 932.5 mm x 441.8 mm x 1295.7 mm

Order Information

Order number

Description

OL5004-26-027 CyBio QuadPrint HQ-M, automated high throughput barcode/text printing, labeling and stacking of microlpates
OL5004-26-025 CyBio QuadPrint HQ, automated high throughput barcode/text printing and labeling
OL5004-26-026 CyBio QuadPrint HQ-L, automated high throughput barcode/text printing, labeling and stacking of microlpates

Accessories

Compressor Jun-Air

Order number: OL3803-22-130

Software

CyBio PrintStudio

The combination of CyBio Composer with the improved CyBio PrintStudio enables reliable control of the CyBio QuadPrint. This includes the ergonomic design of label layouts as well as the import of label lists and printing of MTP labels.



System requirements:

  • CyBio Composer 2.67.00.00 or higher
  • CyBio PrintStudio 1.1.0 or higher
  • .NET Framework 4.8 or higher
  • Microsoft Visual C++ Runtime 2017 or higher
Product Required Included
CyBio QuadPrint HQ-M (OL5004-26-027)
CyBio QuadPrint HQ (OL5004-26-025)
CyBio QuadPrint HQ-L (OL5004-26-026)

CyBio Scheduler Software

Order number: OL9515-40-001

The CyBio Scheduler software allows for the parallel and time-optimized control of several laboratory instruments to execute a number of diverse workflows. The Software provides flexibility and precision to run your automation system. No matter how complex your assays are, with CyBio Scheduler you will achieve reproducible and uniform conditions and assay results for each individual plate.

  • Easy drag & drop workflow creation
  • Powerful and fast assay optimization
  • Precise fast assay simulation
  • Automatic synchronization and optimization
  • Scheduled processing including online visualization
  • Cycle and assay interleaving
  • Multi-faceted interfaces with your LIMS, network and database
  • Versatile error recovery and message services
  • Tracking of all relevant sub-processes
  • Identification and status of all microplates in the process
  • Easy data import and export
Product Required Included
CyBio QuadPrint HQ-M (OL5004-26-027)
CyBio QuadPrint HQ (OL5004-26-025)
CyBio QuadPrint HQ-L (OL5004-26-026)

Consumables

Order number Name
0918906-00 Labels 66.0 x 5.5 mm; spacing 14 mm; DMSO resistant
0918905-00 Labels 66.0 x 7.0 mm; spacing 14 mm; DMSO resistant
0918903-00 Ribbon for label printers
