Hydride Systems Extended Application of AAS

Modular hydride systems for the analysis of mercury and hydride-forming elements
Application-specific batch or flow injection setup
Mercury trace analysis due to additional enrichment
Compliant with DIN, ISO, EPA and ASTM methods for mercury and hydride testing

Cold Vapor Technology to Determine Mercury and Hydride Forming Elements

Flow and batch mode for high throughput and low detection limits
Amalgamation module for the best detection limits in mercury testing
Color-coded tubing connections for simple, unambiguous replacement of consumables
Optimized gas-liquid paths and dedicated material selection to reduce contamination and memory-effects
Intelligent valve control for short measurement and rinsing times

Trace Analysis for Any Demand

The hydride series as additional accesory for the AAS include different systems for all requirements from the simplest application with the HS 50, the semi-automated batch mode system HS 55, well suited for difficult sample matrices, up to the fully automated sample preparation and hydride forming with the flow injection system HS 60. Lowest detection limits are achieved for mercury and the hydride forming elements such as antimony, arsenic, and selenium in flame and graphite furnace mode with various upgrade options.

Amalgamation mode for ultra trace analysis of mercury
HydrEA upgrade Kit - for ultra trace analysis of hydride elements in furnace mode

Products

Hg/Hydrid-System HS 55 - Batch mode system for Hg and hydride forming elements

Relaible results even for demanding samples

Order number: 810-60404-2

Hg/Hydride System HS 50 - Manual hydride system with flame heated quartz cell atomizer

Cost-effective Hydride system for simple application

Order number: 810-60149-2

Hg/Hydride System HS 60 - Flow injection system for Hg and hydride forming elements

Fully automated sample handling for high sample troughput in routine work

Order number: 810-60402-2

Order Information

Order number	Description
810-60404-2	Hg/Hydrid-System HS 55 Batch mode system for Hg and hydride forming elements
810-60149-2	Hg/Hydride System HS 50 Manual hydride system with flame heated quartz cell atomizer
810-60402-2	Hg/Hydride System HS 60 Flow injection system for Hg and hydride forming elements

Accessories

Hg cell (tulip) - for improved Hg sensitivity

Order number: 810-60051-0

Hg Plus Upgrade Module for Hg enrichment, extension of Hg/Hydride-Systems HS 55 and HS 60

Order number: 810-60406-0

HydrEA Upgrade Kit for coupling hydride systems HS 55 and HS 60 with graphite furnace AAS

Order number: 810-60509-0

Consumables

Order number	Name
407-10-1700-102-11	Bottle acid, 1L for AAS hydride systems
407-10-1700-101-11	Bottle reducing agent, 1L for ICP/AAS hydride systems
407-10-1700-087-11	cell tube for AAS hydride system HS 55
407-170.537	Connection tube cell for AAS hydride systems
407-170.544	Coupler for drying hose for AAS hydride systems
407-170.543	Drying tube Hg for AAS hydride systems
407-170.548	Drying-tube hydrid for AAS hydride systems
407-170.590	Gas liquid separator for AAS hydride systems
407-10-1700-095-11	pump tube reducing agent for AAS hydride systems
702-A54.012	Quartz cell without windows for AAS hydride systems HS 55, HS 60
702-A65.021	reaction beaker PTFE with conical bottom, flange seal, for HS 55
407-10-1700-102-25	Set connection tubes for AAS hydride system (HS 60)
407-10-1700-101-25	Set of pump tubes for AAS hydride system (HS 60)
407-170.600	Set window with ring for AAS hydride systems HS 55/HS 60

Downloads

Title	Language	Info
Operating Manual HS 50 (DE)	German	PDF, 1 MB
Operating Manual HS 50 (EN)	English	PDF, 1 MB
Operating Manual HS 50 (RU)	Russian	PDF, 748 KB
Operating Manual HS 55 modular (DE)	German	PDF, 5 MB
Operating Manual HS 55 modular (EN)	English	PDF, 5 MB
Operating Manual HS 55 modular (ES)	Spanish	PDF, 6 MB
Operating Manual HS 55 modular (FR)	French	PDF, 6 MB
Operating Manual HS 60 modular (DE)	German	PDF, 7 MB
Operating Manual HS 60 modular (EN)	English	PDF, 7 MB
Operating Manual HS 60 modular (ES)	Spanish	PDF, 7 MB
Operating Manual HS 60 modular (FR)	French	PDF, 7 MB
